Archos 50 NEON
Archos 50 NEON
Teardown difficulty:
Easy
Duration:
4 min

Recommended tools

Screwdriver Phillips #000 Screwdriver phillips #000
Opening tool / Spudger Opening tool / spudger
Tweezers Tweezers

Disassembly/Repair of the mobile device Archos 50 NEON with each step description and the required set of tools.

Vadim Popoff

Author, currently - Quality Assurance Specialist

How to disassemble Archos 50 NEON, Step 1/1 How to disassemble Archos 50 NEON, Step 1/2

Step 1.

Open the back cover.

How to disassemble Archos 50 NEON, Step 2/1 How to disassemble Archos 50 NEON, Step 2/2

Step 2.

Lift and remove the battery.

How to disassemble Archos 50 NEON, Step 3/1 How to disassemble Archos 50 NEON, Step 3/2

Step 3.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 11 bolts in the frame of the phone.

How to disassemble Archos 50 NEON, Step 4/1 How to disassemble Archos 50 NEON, Step 4/2

Step 4.

Pry and remove the middle frame.

How to disassemble Archos 50 NEON, Step 5/1 How to disassemble Archos 50 NEON, Step 5/2 How to disassemble Archos 50 NEON, Step 5/3 How to disassemble Archos 50 NEON, Step 5/4

Step 5.

Disconnect connectors and pry & remove the flexible flat cable with volume and power buttons.

How to disassemble Archos 50 NEON, Step 6/1 How to disassemble Archos 50 NEON, Step 6/2

Step 6.

Remove the PCB.

How to disassemble Archos 50 NEON, Step 7/1 How to disassemble Archos 50 NEON, Step 7/2 How to disassemble Archos 50 NEON, Step 7/3

Step 7.

Parts in the frame of the display module.

Detailed disassembly instructions of Archos 50 NEON in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.

#instructions #Archos #Archos 50 NEON
Evgenii Kuzmin

Evgenii Kuzmin

Senior maintenance service and repair engineer

Disassembling\Repair has easy complexity and takes about 4 minutes in time.
Our manual is suitable for all models Archos 50 NEON released for markets in different countries.
