Samsung Galaxy J2 SM-J200

Teardown difficulty:
Moderate

Duration:
8 min

Recommended tools

Heat gun

Screwdriver phillips #000

Opening tool / spudger

Tweezers

Disassembly/Repair of the mobile device Samsung Galaxy J2 SM-J200 (Samsung J200F (UAE, Turkey); J200Y (New Zealand, Taiwan); J200G (India, Indonesia); J200H with no LTE (South Africa, Kazakhstan); J200GU (Philippines, Malaysia, Thailand)) with each step description and the required set of tools.

Vadim Popoff

Quality assurance specialist

Author, currently - Quality Assurance Specialist

Step 1.

Open the back cover.

How to disassemble Samsung Galaxy J2 SM-J200, Step 2/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 2/2

Step 2.

Lift and remove the battery.

How to disassemble Samsung Galaxy J2 SM-J200, Step 3/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 3/2

Step 3.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 9 bolts in the frame of the phone.

How to disassemble Samsung Galaxy J2 SM-J200, Step 4/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 4/2

How to disassemble Samsung Galaxy J2 SM-J200, Step 4/3

Step 4.

Pry and remove the middle frame.

⚠️ Warning!

For careful separation, we recommend using a heat gun. At the same time, it is necessary to heat carefully in order, not to damage the surface of the device.

How to disassemble Samsung Galaxy J2 SM-J200, Step 5/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 5/2

Step 5.

Pry and remove the buzzer (speaker).

How to disassemble Samsung Galaxy J2 SM-J200, Step 6/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 6/2

Step 6.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 2 bolts in the PCB.

How to disassemble Samsung Galaxy J2 SM-J200, Step 7/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 7/2

Step 7.

Disconnect the connector on PCB, and remove the front (selfie) camera.

How to disassemble Samsung Galaxy J2 SM-J200, Step 8/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 8/2

How to disassemble Samsung Galaxy J2 SM-J200, Step 8/3

How to disassemble Samsung Galaxy J2 SM-J200, Step 8/4

How to disassemble Samsung Galaxy J2 SM-J200, Step 8/5

Step 8.

Disconnect connectors on the PCB.

How to disassemble Samsung Galaxy J2 SM-J200, Step 9/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 9/2

Step 9.

Remove the PCB.

How to disassemble Samsung Galaxy J2 SM-J200, Step 10/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 10/2

Step 10.

Pry & remove the vibration motor.

How to disassemble Samsung Galaxy J2 SM-J200, Step 11/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 11/2

Step 11.

Pry and remove the cable with a earpiece (speaker) and headphone jack/socket.

How to disassemble Samsung Galaxy J2 SM-J200, Step 12/1

How to disassemble Samsung Galaxy J2 SM-J200, Step 12/2

How to disassemble Samsung Galaxy J2 SM-J200, Step 12/3

Step 12.

Parts are in the frame of the display module.

Detailed disassembly instructions of Samsung Galaxy J2 SM-J200 in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.

#instructions #Samsung #Samsung Galaxy J2 SM-J200

Evgenii Kuzmin

Senior maintenance service and repair engineer

Disassembling\Repair has medium complexity and takes about 8 minutes in time.
Our manual is suitable for all models Samsung Galaxy J2 SM-J200 — Samsung J200F (UAE, Turkey); J200Y (New Zealand, Taiwan); J200G (India, Indonesia); J200H with no LTE (South Africa, Kazakhstan); J200GU (Philippines, Malaysia, Thailand) released for markets in different countries.
