Archos 50 NEON
Archos 50 NEON
Teardown difficulty:
Easy
Duration:
4 min

Recommended tools

Screwdriver Phillips #000 Screwdriver phillips #000
Opening tool / Spudger Opening tool / spudger
Tweezers Tweezers

Disassembly/Repair of the mobile device Archos 50 NEON with each step description and the required set of tools.

Vadim Popoff

Specialist in content creation, distribution and content management.

How to disassemble Archos 50 NEON, Step 1/1 How to disassemble Archos 50 NEON, Step 1/2

Step 1.

Open the back cover.

How to disassemble Archos 50 NEON, Step 2/1 How to disassemble Archos 50 NEON, Step 2/2

Step 2.

Lift and remove the battery.

How to disassemble Archos 50 NEON, Step 3/1 How to disassemble Archos 50 NEON, Step 3/2

Step 3.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 11 bolts in the frame of the phone.

How to disassemble Archos 50 NEON, Step 4/1 How to disassemble Archos 50 NEON, Step 4/2

Step 4.

Pry and remove the middle frame.

How to disassemble Archos 50 NEON, Step 5/1 How to disassemble Archos 50 NEON, Step 5/2 How to disassemble Archos 50 NEON, Step 5/3 How to disassemble Archos 50 NEON, Step 5/4

Step 5.

Disconnect connectors and pry & remove the flexible flat cable with volume and power buttons.

How to disassemble Archos 50 NEON, Step 6/1 How to disassemble Archos 50 NEON, Step 6/2

Step 6.

Remove the PCB.

How to disassemble Archos 50 NEON, Step 7/1 How to disassemble Archos 50 NEON, Step 7/2 How to disassemble Archos 50 NEON, Step 7/3

Step 7.

Parts in the frame of the display module.

Detailed disassembly instructions of Archos 50 NEON in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.

#instructions #Archos #Archos 50 NEON
Evgenii Kuzmin

Evgenii Kuzmin

Senior maintenance service and repair engineer

Disassembling\Repair has easy complexity and takes about 4 minutes in time.
Our manual is suitable for all models Archos 50 NEON released for markets in different countries.
