Disassembly of the mobile device Samsung Galaxy A5 SM-A500 (Samsung A500F (Global), A500FU (Europe), A500M (Peru, Colombia), A500Y (Australia, New Zealand), A500YZ (Taiwan), A500F1/A500K/A500S (Korea), A500FQ (Turkey)) with each step description and the required set of tools.

Load more

Specialist in content creation, distribution and content management.


How to disassemble Samsung Galaxy A5 SM-A500, Step 1/1

Step 1

⚠️ Warning!

Before the disassembly, it is necessary! Separate the display module, in more detail in our video link


How to disassemble Samsung Galaxy A5 SM-A500, Step 2/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 2/2

Step 2

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 13 bolts in the frame of the phone.


How to disassemble Samsung Galaxy A5 SM-A500, Step 3/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 3/2 How to disassemble Samsung Galaxy A5 SM-A500, Step 3/3

Step 3

Pry & remove the cover.


How to disassemble Samsung Galaxy A5 SM-A500, Step 4/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 4/2 How to disassemble Samsung Galaxy A5 SM-A500, Step 4/3

Step 4

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 1 bolt in the lower PCB.


How to disassemble Samsung Galaxy A5 SM-A500, Step 5/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 5/2 How to disassemble Samsung Galaxy A5 SM-A500, Step 5/3

Step 5

Pry up the battery connector and separate the battery from the frame.

⚠️ Warning!

For careful separation, we recommend using a heat gun. At the same time, it is necessary to heat carefully in order, not to damage the surface of the device.


How to disassemble Samsung Galaxy A5 SM-A500, Step 6/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 6/2 How to disassemble Samsung Galaxy A5 SM-A500, Step 6/3 How to disassemble Samsung Galaxy A5 SM-A500, Step 6/4 How to disassemble Samsung Galaxy A5 SM-A500, Step 6/5 How to disassemble Samsung Galaxy A5 SM-A500, Step 6/6

Step 6

Disconnect connectors and remove the main PCB.


How to disassemble Samsung Galaxy A5 SM-A500, Step 7/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 7/2 How to disassemble Samsung Galaxy A5 SM-A500, Step 7/3

Step 7

Pry and remove the lower PCB.


How to disassemble Samsung Galaxy A5 SM-A500, Step 8/1 How to disassemble Samsung Galaxy A5 SM-A500, Step 8/2 How to disassemble Samsung Galaxy A5 SM-A500, Step 8/3

Step 8

Parts in the middle frame.

Detailed disassembly instructions of Samsung Galaxy A5 SM-A500 in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.

Load more

Disassembling\Repair has hard complexity and takes about 60 minutes in time. Our manual is suitable for all models Samsung Galaxy A5 SM-A500 — Samsung A500F (Global), A500FU (Europe), A500M (Peru, Colombia), A500Y (Australia, New Zealand), A500YZ (Taiwan), A500F1/A500K/A500S (Korea), A500FQ (Turkey) released for markets in different countries.
