Teardown difficulty:
Easy
Duration:
6 min

Recommended tools

Disassembly/Repair of the mobile device Samsung Galaxy Ace Duos GT-S6802 with each step description and the required set of tools.


Specialist in content creation, distribution and content management.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 1/1

Step 1.

Open the back cover.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 2/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 2/2

Step 2.

Lift and remove the battery.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 3/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 3/2

Step 3.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 7 bolts in the frame of the phone.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 4/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 4/2

Step 4.

Pry and remove the middle frame.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 5/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 5/2

Step 5.

Remove the plastic inserts with antennas.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 6/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 6/2

Step 6.

Disconnect the connector on the PCB.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 7/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 7/2

Step 7.

Remove the PCB.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 8/1

Step 8.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 4 bolts in the PCB.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 9/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 9/2

Step 9.

Remove the protective cover.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 10/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 10/2

Step 10.

Disconnect the connector on PCB, and remove the camera.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 11/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 11/2 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 11/3

Step 11.

Pry up the touchscreen connector.


How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 12/1 How to disassemble Samsung Galaxy Ace Duos GT-S6802, Step 12/2

Step 12.

Separate the display from the frame. Also, remove the Home button key.

Detailed disassembly instructions of Samsung Galaxy Ace Duos GT-S6802 in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.


Disassembling\Repair has easy complexity and takes about 6 minutes in time.
Our manual is suitable for all models Samsung Galaxy Ace Duos GT-S6802 released for markets in different countries.
