Disassembly of the mobile device Xiaomi Black Shark 3 with each step description and the required set of tools.


Specialist in content creation, distribution and content management.


How to disassemble Xiaomi Black Shark 3, Step 1/1 How to disassemble Xiaomi Black Shark 3, Step 1/2

Step 1. Before disassembling!

⚠️ Before disassembling, do not forget to turn your phone off.


How to disassemble Xiaomi Black Shark 3, Step 2/1

Step 2. Open the display module

⚠️ Pay attention!

Steps 2 to 5 are about removing the display module. We need it when we want to remove the motherboard.

If you don't want to remove the motherboard, please, skip to step 6.

⚠️ Pay attention! Disassembly has a maximum 3rd difficulty because the process begins with the disassembly of the display module. If you have no experience or are not sure of your skills, we strongly recommend that you contact a specialized service center.

We recommend using a special heating device such as a separator machine, heat gun, or heating mat. It will simplify the process. You can use a home hairdryer, but you will have to make a nozzle by hand or have a suitable one in the kit to gently heat and concentrate the heat flow in the right place.

ℹ️️ The surface of the display module must be heated to soften the adhesive underneath. The approximate heating temperature is 50° C / 125° F.

Use a thin plastic film or pick for separation. To facilitate the process, you can use isopropyl alcohol. It is often most difficult to pass the tool between the parts to be divided. Choose the far edge from the FFC cables or buttons.

Do not use a lever or any force for separation that could damage the elements inside.


How to disassemble Xiaomi Black Shark 3, Step 3/1 How to disassemble Xiaomi Black Shark 3, Step 3/2

Step 3. Unscrew the screws

Using a screwdriver (Phillips 1.5 mm PH000), unscrew two screws and remove the bracket securing the display module cable.

⚠️ Cable are glued to the housing, so be careful.


How to disassemble Xiaomi Black Shark 3, Step 4/1 How to disassemble Xiaomi Black Shark 3, Step 4/2

Step 4. Unscrew one screw

Using a screwdriver (Phillips 1.5 mm PH000), unscrew one screw and remove the bracket securing the display module cable connector.


How to disassemble Xiaomi Black Shark 3, Step 5/1

Step 5. Disconnect the connector

Pry up the connector and remove the display module.


How to disassemble Xiaomi Black Shark 3, Step 6/1 How to disassemble Xiaomi Black Shark 3, Step 6/2 How to disassemble Xiaomi Black Shark 3, Step 6/3 How to disassemble Xiaomi Black Shark 3, Step 6/4 How to disassemble Xiaomi Black Shark 3, Step 6/5 How to disassemble Xiaomi Black Shark 3, Step 6/6 How to disassemble Xiaomi Black Shark 3, Step 6/7 How to disassemble Xiaomi Black Shark 3, Step 6/8

Step 6. Open the back cover

We recommend using a special heating device such as a separator machine, heat gun, or heating mat. It will simplify the process. You can use a home hairdryer, but you will have to make a nozzle by hand or have a suitable one in the kit to gently heat and concentrate the heat flow in the right place.

ℹ️️ The surface of the back cover must be heated to soften the adhesive underneath. The approximate heating temperature is 50° C / 125° F.

Use a thin plastic film or pick for separation. To facilitate the process, you can use isopropyl alcohol. It is often most difficult to pass the tool between the parts to be divided. Choose the far edge from the FFC cables or buttons.

Do not use a lever or any force for separation that could damage the elements inside.

ℹ️️ Turn the cover over. Be careful with the LED cable. It is still connected to the motherboard and is held by the bracket.


How to disassemble Xiaomi Black Shark 3, Step 7/1 How to disassemble Xiaomi Black Shark 3, Step 7/2 How to disassemble Xiaomi Black Shark 3, Step 7/3 How to disassemble Xiaomi Black Shark 3, Step 7/4

Step 7. Unscrew the screws

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 3 screws and remove the bracket holding the connectors.


How to disassemble Xiaomi Black Shark 3, Step 8/1 How to disassemble Xiaomi Black Shark 3, Step 8/2

Step 8. Disconnect the connector

Pry up the connector and remove the back cover.

⚠️ Please use a non-metal or plastic tool because the motherboard is still powered.


How to disassemble Xiaomi Black Shark 3, Step 9/1 How to disassemble Xiaomi Black Shark 3, Step 9/2 How to disassemble Xiaomi Black Shark 3, Step 9/3 How to disassemble Xiaomi Black Shark 3, Step 9/4

Step 9. Disconnect the battery connector

Disconnect the two battery connectors.

ℹ️️ The Xiaomi Black Shark 3 model has two batteries BS06FA with 3000 mAh capacity each (aka rechargeable battery).

⚠️ Please use a non-metal or plastic tool to avoid any damage.


How to disassemble Xiaomi Black Shark 3, Step 10/1 How to disassemble Xiaomi Black Shark 3, Step 10/2 How to disassemble Xiaomi Black Shark 3, Step 10/3 How to disassemble Xiaomi Black Shark 3, Step 10/4 How to disassemble Xiaomi Black Shark 3, Step 10/5

Step 10. Unscrew the screws

Using a screwdriver (Phillips 1.5 mm PH000), unscrew four screws and remove the cover securing the motherboard.


How to disassemble Xiaomi Black Shark 3, Step 11/1 How to disassemble Xiaomi Black Shark 3, Step 11/2 How to disassemble Xiaomi Black Shark 3, Step 11/3 How to disassemble Xiaomi Black Shark 3, Step 11/4

Step 11. Remove the rear camera

Pry up the connectors and remove the three rear cameras assembly.


How to disassemble Xiaomi Black Shark 3, Step 12/1 How to disassemble Xiaomi Black Shark 3, Step 12/2 How to disassemble Xiaomi Black Shark 3, Step 12/3 How to disassemble Xiaomi Black Shark 3, Step 12/4

Step 12. Unscrew the screws

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 3 screws and remove the cover.

Also, pry up the flat metal cable's end with the microphone.


How to disassemble Xiaomi Black Shark 3, Step 13/1 How to disassemble Xiaomi Black Shark 3, Step 13/2 How to disassemble Xiaomi Black Shark 3, Step 13/3 How to disassemble Xiaomi Black Shark 3, Step 13/4

Step 13. Remove the front camera

Disconnect the connector, peel off the long cable and remove the front (selfie) camera.


How to disassemble Xiaomi Black Shark 3, Step 14/1 How to disassemble Xiaomi Black Shark 3, Step 14/2 How to disassemble Xiaomi Black Shark 3, Step 14/3

Step 14. Unscrew the screws

Using a screwdriver (Phillips 1.5 mm PH000), unscrew four screws.


How to disassemble Xiaomi Black Shark 3, Step 15/1 How to disassemble Xiaomi Black Shark 3, Step 15/2 How to disassemble Xiaomi Black Shark 3, Step 15/3

Step 15. Open the cover

Remove the cover.


How to disassemble Xiaomi Black Shark 3, Step 16/1 How to disassemble Xiaomi Black Shark 3, Step 16/2 How to disassemble Xiaomi Black Shark 3, Step 16/3

Step 16. Unscrew the screws

Using a screwdriver (Phillips 1.5 mm PH000), unscrew three black and two long silver screws.

ℹ️️ Be sure to note the location of the screws before disassembling. When assembling the device, screwing the screw in the wrong place may damage the device or its parts. To avoid damage, the removed screws and individual pieces (as gaskets or brackets) must be laid out in the appropriate order, or the screws and their holes in the phone must be marked with colored markers.


How to disassemble Xiaomi Black Shark 3, Step 17/1 How to disassemble Xiaomi Black Shark 3, Step 17/2 How to disassemble Xiaomi Black Shark 3, Step 17/3 How to disassemble Xiaomi Black Shark 3, Step 17/4 How to disassemble Xiaomi Black Shark 3, Step 17/5 How to disassemble Xiaomi Black Shark 3, Step 17/6

Step 17. Remove the loudspeaker

Disconnect the coaxial cable connector and remove the loudspeaker assembly.


How to disassemble Xiaomi Black Shark 3, Step 18/1 How to disassemble Xiaomi Black Shark 3, Step 18/2 How to disassemble Xiaomi Black Shark 3, Step 18/3 How to disassemble Xiaomi Black Shark 3, Step 18/4

Step 18. Unscrew the screws

Using a screwdriver (Philips 2.5 mm aka iPhone), unscrew three barrel screws.


How to disassemble Xiaomi Black Shark 3, Step 19/1 How to disassemble Xiaomi Black Shark 3, Step 19/2 How to disassemble Xiaomi Black Shark 3, Step 19/3 How to disassemble Xiaomi Black Shark 3, Step 19/4

Step 19. Disconnect the connectors

Disconnect all connectors.


How to disassemble Xiaomi Black Shark 3, Step 20/1 How to disassemble Xiaomi Black Shark 3, Step 20/2 How to disassemble Xiaomi Black Shark 3, Step 20/3 How to disassemble Xiaomi Black Shark 3, Step 20/4 How to disassemble Xiaomi Black Shark 3, Step 20/5 How to disassemble Xiaomi Black Shark 3, Step 20/6 How to disassemble Xiaomi Black Shark 3, Step 20/7 How to disassemble Xiaomi Black Shark 3, Step 20/8 How to disassemble Xiaomi Black Shark 3, Step 20/9

Step 20. Remove the motherboard

⚠️ Pay attention! First, we should release the headphone jack socket. Peel off the cable with the headphone jack socket and microphone glued to the housing.

Carefully remove the printed circuit board. There is no need to use a lever or try to reach the board by force. Make sure that nothing is getting in the way or holding the board.

⚠️ Do not bend the circuit board when removing it or push tools under it. Unbeknownst to yourself, you can damage components or cables from the inside.

⚠️ Pay attention! The motherboard may be glued with protective film from the inside, so just turn the phone over and carefully peel the film off.


How to disassemble Xiaomi Black Shark 3, Step 21/1 How to disassemble Xiaomi Black Shark 3, Step 21/2 How to disassemble Xiaomi Black Shark 3, Step 21/3 How to disassemble Xiaomi Black Shark 3, Step 21/4

Step 21. In the housing remained

ℹ️️ In the housing remained: the earpiece speaker, batteries, vibration motor, charging port, small boards, coaxial cables.

Detailed disassembly instructions of Xiaomi Black Shark 3 in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.


Disassembling\Repair has hard complexity and takes about minutes in time. Our manual is suitable for all models Xiaomi Black Shark 3 released for markets in different countries.
