Teardown difficulty:
Hard
Duration:
15 min

Recommended tools

Disassembly/Repair of the mobile device Land Rover HG11A with each step description and the required set of tools.


Author, currently - Quality Assurance Specialist


How to disassemble Land Rover HG11A, Step 1/1 How to disassemble Land Rover HG11A, Step 1/2

Step 1.

Separate the display module from the cover.

⚠️ Warning!

For careful separation, we recommend using a heat gun. At the same time, it is necessary to heat carefully in order, not to damage the surface of the device.


How to disassemble Land Rover HG11A, Step 2/1 How to disassemble Land Rover HG11A, Step 2/2

Step 2.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 1 bolt and remove the bracket holding the connectors.


How to disassemble Land Rover HG11A, Step 3/1 How to disassemble Land Rover HG11A, Step 3/2 How to disassemble Land Rover HG11A, Step 3/3

Step 3.

Pry up the connector and remove the display module.


How to disassemble Land Rover HG11A, Step 4/1 How to disassemble Land Rover HG11A, Step 4/2

Step 4.

Using a tweezers, open the SIM and Micro SD cards tray and remove it.


How to disassemble Land Rover HG11A, Step 5/1 How to disassemble Land Rover HG11A, Step 5/2

Step 5.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 11 bolts in the frame of the phone.


How to disassemble Land Rover HG11A, Step 6/1 How to disassemble Land Rover HG11A, Step 6/2

Step 6.

Pry and remove the middle cover.


How to disassemble Land Rover HG11A, Step 7/1 How to disassemble Land Rover HG11A, Step 7/2

Step 7.

Using a screwdriver (Phillips 1.5 mm PH000), unscrew 2 bolts in the lower PCB.


How to disassemble Land Rover HG11A, Step 8/1 How to disassemble Land Rover HG11A, Step 8/2 How to disassemble Land Rover HG11A, Step 8/3

Step 8.

Pry up the connector of the inter-board cable on the main board, coaxial cable connector on the lower one, unsolder the wires of the vibration motor, and remove the lower PCB with the inter-board cable.


How to disassemble Land Rover HG11A, Step 9/1 How to disassemble Land Rover HG11A, Step 9/2

Step 9.

Disconnect the connector on PCB, and remove the front (selfie) camera.


How to disassemble Land Rover HG11A, Step 10/1 How to disassemble Land Rover HG11A, Step 10/2

Step 10.

Overturn the board, disconnect the connectors from the inside and remove it.


How to disassemble Land Rover HG11A, Step 11/1 How to disassemble Land Rover HG11A, Step 11/2

Step 11.

Separate the battery from the frame.

Detailed disassembly instructions of Land Rover HG11A in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.


Disassembling\Repair has hard complexity and takes about 15 minutes in time.
Our manual is suitable for all models Land Rover HG11A released for markets in different countries.
