Sony Ericsson Xperia X10
Sony Ericsson Xperia X10
Teardown difficulty:
Easy
Duration:
6 min

Recommended tools

Screwdriver Torx T6 Screwdriver torx t6
Opening tool / Spudger Opening tool / spudger
Tweezers Tweezers

Disassembly/Repair of the mobile device Sony Ericsson Xperia X10 (Sony Ericsson Xperia X10 Es209ra) with each step description and the required set of tools.

Vadim Popoff

Author, currently - Quality Assurance Specialist

How to disassemble Sony Ericsson Xperia X10, Step 1/1 How to disassemble Sony Ericsson Xperia X10, Step 1/2

Step 1.

Open the back cover.

How to disassemble Sony Ericsson Xperia X10, Step 2/1 How to disassemble Sony Ericsson Xperia X10, Step 2/2

Step 2.

Lift and remove the battery.

How to disassemble Sony Ericsson Xperia X10, Step 3/1 How to disassemble Sony Ericsson Xperia X10, Step 3/2

Step 3.

Using a screwdriver (hex T6), unscrew 8 bolts in the frame of the phone.

How to disassemble Sony Ericsson Xperia X10, Step 4/1 How to disassemble Sony Ericsson Xperia X10, Step 4/2

Step 4.

Pry and remove the middle frame and keys of the volume and power buttons.

How to disassemble Sony Ericsson Xperia X10, Step 5/1 How to disassemble Sony Ericsson Xperia X10, Step 5/2 How to disassemble Sony Ericsson Xperia X10, Step 5/3

Step 5.

Turm over the board with Sim & MMC card holders on one side and the buzzer (speaker) on another one. Disconnect the connector and remove the board.

How to disassemble Sony Ericsson Xperia X10, Step 6/1 How to disassemble Sony Ericsson Xperia X10, Step 6/2

Step 6.

Pry and remove the headphone jack/socket.

How to disassemble Sony Ericsson Xperia X10, Step 7/1 How to disassemble Sony Ericsson Xperia X10, Step 7/2 How to disassemble Sony Ericsson Xperia X10, Step 7/3 How to disassemble Sony Ericsson Xperia X10, Step 7/4

Step 7.

Disconnect connectors on the PCB.

How to disassemble Sony Ericsson Xperia X10, Step 8/1 How to disassemble Sony Ericsson Xperia X10, Step 8/2

Step 8.

Remove the PCB.

How to disassemble Sony Ericsson Xperia X10, Step 9/1 How to disassemble Sony Ericsson Xperia X10, Step 9/2

Step 9.

Remove the buttons board.

How to disassemble Sony Ericsson Xperia X10, Step 10/1 How to disassemble Sony Ericsson Xperia X10, Step 10/2

Step 10.

Separate the display from the frame with a touchscreen.

How to disassemble Sony Ericsson Xperia X10, Step 11/1

Step 11.

The frame with a touchscreen.

Detailed disassembly instructions of Sony Ericsson Xperia X10 in the video, made by our mobile repair & service center:

If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.

#instructions #Sony Ericsson #Sony Ericsson Xperia X10
Evgenii Kuzmin

Evgenii Kuzmin

Senior maintenance service and repair engineer

Disassembling\Repair has easy complexity and takes about 6 minutes in time.
Our manual is suitable for all models Sony Ericsson Xperia X10 — Sony Ericsson Xperia X10 Es209ra released for markets in different countries.
