General characteristics ZTE Blade S6 declared by the manufacturer. The high-resolution pictures of the motherboard and electronic components.
Main and additional circuit boards ZTE Blade S6
Side 1
Side 2
Characteristics
Features
Type
Smartphone
OS
Android 5.1 (Lollipop)
SIM type/size
Nano SIM
SIM
Dual SIM
Dimensions
144 x 70.7 x 7.7 mm (5.67 x 2.78 x 0.30 in)
Weight
154 g (5.43 oz)
Display
Display type
IPS LCD
Size
5.0 inches
Resolution
720 x 1280 pixels, 16:9 ratio
PPI density
294
Protection
---
Multimedia
Main camera
13 MP
Main camera Video
1080p, 30fps
Front (selfie) camera
5 MP
Front (selfie) camera Video
1080p, 30fps
Audio
MP3, FM-radio
Headphone jack
Mini jack 3.5 mm
Network
Technology
GSM/ 3G/ 4G LTE
LTE
Yes, Bands 1, 3, 7, 8, 20
Interfaces
Wi-Fi 802.11n, Bluetooth 4.0
Satellite navigation
GPS with A-GPS
Processor and Memory
System on a chip
Qualcomm MSM8939 Snapdragon 615
CPU
Octa-core 4x Cortex-A53 1.5 GHz + 4x Cortex-A53 1.0 GHz
GPU
Adreno 405
Internal memory
16 GB
RAM
2 GB
Card slot
Micro SD, up to 32 GB (dedicated slot)
Battery
Battery capacity
Li-Ion 2400 mAh
Charging port
Micro USB 2.0
Other
Announced
2015, January
If you have a question, ask us, and we will try to answer in as much detail as possible. If this article was helpful for you, please rate it.
Based on our experience, we made a selection of the most common malfunctions of mobile devices and evaluated the difficulty of performing repairs for each of them. The final evaluation of the difficulty of the repair is the sum of all the parameters.
This difficulty rating is also applicable for all models ZTE Blade S6 released for markets in different countries.
