Disassembly/Repair of the mobile device Yandex.Phone with each step description and the required set of tools.

Use the ejection tool (aka Needle) or Paperclip. Push the tip all the way into the hole until the tray ejects, and then pull the tray of SIM and Memory card (Micro SD) out.

⚠️️ Pay attention! The tool must be inserted into a hole on the edge of the phone's housing. Do not press too hard. It may break the tray eject mechanism.

We recommend using a special heating device such as a separator machine, heat gun, or heating mat. It will simplify the process. You can use a home hairdryer, but you will have to make a nozzle by hand or have a suitable one in the kit to gently heat and concentrate the heat flow in the right place.

ℹ️️ The surface of the back cover must be heated to soften the adhesive underneath. The approximate heating temperature is 50° C / 125° F.

Use a thin plastic film or pick for separation. To facilitate the process, you can use isopropyl alcohol. It is often the most difficult to pass the tool between the parts to be divided. Choose the far edge from the FFC cables or buttons.

Do not use a lever or any force for separation that could damage the elements inside.

⚠️️ Pay attention! The body of the fingerprint sensor is slightly glued to the back cover.

Using a screwdriver (Phillips 1.5 mm PH #000), unscrew the six screws.

Pry over the edge and turn over the cover with antenna tracks.

After, disconnect the connector of the fingerprint sensor cable. Try to lift the cover by the edges and not push anything between them to not accidentally touch or short-circuit anything on the circuit board.

Disconnect the battery connector. The battery model of Yandex.Phone is the same.

We strongly recommend disconnecting the connector to avoid a possible short circuit during disassembly.

Disconnect the battery connector as soon as possible. It is better to use a non-metal or plastic tool to avoid any damage.

ℹ️️ The name of the battery model of Yandex.Phone is the same, with 2970 mAh capacity (aka rechargeable battery).

⚠️️ It is highly recommended to disconnect the connector to avoid possible short circuits during disassembly.

Using a screwdriver (Phillips 1.5 mm PH #000), unscrew the six screws.

Pry over the edge and remove the loudspeaker assembly with antenna tracks.

Carefully remove the cover of the microphone.

Pry up the connectors of the inter-board cable, and coaxial cable.

⚠️️ Be careful when removing the cables from the connectors, the cables are pretty thin, and it is easy enough to break them or damage the contact tracks inside.

Remove the sub-board. It may be glued to the frame or attached with attachments like latches or hooks, so be careful.

ℹ️️ The sub-board contains a charging port (Micro USB), microphone, spring contacts for the speaker, vibration motor, and an antenna unit.

⚠️️ It is not necessary to insert the tool underneath when removing the sub-board. Internal components could be damaged.

Pry up the connectors of the display module cable, inter-board cable, and two coaxial cables.

⚠️️ Be careful when removing the cables from the connectors, the cables are pretty thin, and it is easy enough to break them or damage the contact tracks inside.

Peel off the copper film covering the front camera. Disconnect the connectors and remove two rear cameras and one front (selfie) camera.

Carefully remove the printed circuit board. There is no need to use a lever or try to reach the circuit board by force. Make sure that nothing is getting in the way or holding the circuit board.

The motherboard, also, may be attached with attachments like latches or hooks, be careful.

⚠️️ Do not bend the circuit board when removing it or push tools under it. Unbeknownst to yourself, you can damage components or cables from the inside.

ℹ️️ In the display frame remained: the earpiece speaker, battery, vibration motor, small board, coaxial cables.
